Star Hanger Fasteners Applications

The Zero can be used both to mount to furring and mount to drywall. a  hidden fastener, that The Zero allows for the fast and easy installation of panels, directly into place with zero reveal.
Star Hanger, Star Zero a fast, economical and removable snap in insert, they don't require the 3/8
The Star Zero  3/16
Zero Reveal Fastener System
Star Hanger project showing a Star Zero used to install ADA removeable access panel.
Star Hanger rendering of Star Zero & a Star Mounting Bolt used to install artwork directly onto sheetrock. The panels install by snapping the panels directly into place with zero reveal.
Star Hanger rendering of Star Zero & a Star Mounting Bolt used to install artwork directly onto sheetrock. The panels install by snapping the panels directly into place with zero reveal.
Star Hanger rendering of Star Zero used to install preassembled booth seating onto the CNC precut booth rips. The fabric covered seat installs by pushing the panels straight down to lock them into place.
Star Hanger rendering of Star Zero used to install a CNC pre cut ADA Unit with a removeable ADA access panel.
Star Hanger rendering of Star Zero & Star Green Glide used to install a preassembled wood soffit onto a preassembled
Star Hanger rendering of Star Zero & a Star Mounting Bolt used to install wood moulding and trim directly onto sheetrock. The moulding installs by snapping directly into place with no drop down space required, zero reveal.
Star Hanger rendering of Star Zero & a Star Mounting Bolt used to install acoustical panels directly onto sheetrock. both  acoustical panels and  Fabric Panels can be  installed by snapping directly into place with no drop down space required, zero reveal.
Star Hanger rendering of Star Zero & Star Red Snaper used to install a preassembled wood soffit onto a preassembled
320 Zero, 5/16
320 Zero, 5/16
320 Zero, 5/16
320 Zero, 5/16
320 Zero, 5/16
×

320 Zero, 5/16" Gap, (25 Lbs. Blue)

The 320 Zero can be used both to mount to furring and mount to drywall. using field installed or prefabricated furring systems. The 320 Zero is a hidden fastener that allows fast and easy installation of panels directly into place with Zero reveal. Examples include ADA panels, soffit panels, panels with no reveal, fabric panels and wood panels that need to be installed straight into the furring, and for pre-assembled "L" shaped soffits and corners. The 320 Zero holds individual panels, allowing for 1/16" expansion.

Read more

  • Product Description
  • Introduction Animation
  • Installation Guides
  • Demonstration Videos
  • Drawings & Models
  • Product Specifications

320 Zero Diagram

Applications

The 320 Zero can be used both to mount to furring and mount to drywall. using field installed or prefabricated furring systems. The 320 Zero is a hidden fastener that allows fast and easy installation of panels directly into place with Zero reveal. Examples include ADA panels, soffit panels, panels with no reveal, fabric panels and wood panels that need to be installed straight into the furring, and for pre-assembled "L" shaped soffits and corners. The 320 Zero holds individual panels, allowing for 1/16" expansion.

** 334 Euro Screws are Included with the 320 Zero **

Description

The 320 Zero is a medium-duty, one piece, injection-molded insert fastener designed to install panels 'straight-in' with zero reveals. The engineered plastic body and steel screw withstand repeated removal.  The 320 Zero compression fits into a 1.000" drilled hole in any hard substrate. The 320 Zero pushes into a 5/16" mounting screw with about 10 lbs. of force and can be removed with about 25 Lbs. of force, much like a friction catch.

Note: The 320 Zero has a 10 Lb. weight limit.  It should be used overhead only in combination with a mechanically locked clip.
Mounting Screw Size: Our mounting screw heads are the same size as a standard # 10 panhead screw; other screw types and materials will also work.

Cost & Benefit Estimates

320 Zero can be drilled and installed in under a minute. This is notably faster than traditional clips with a similar cost.

Strength Testing  with 3/4", 45 lb. particle board
Tensile: (Pull Out = 25 lb.
Shear (Drop 1/16") = 10 lbs.

320 Zero Strength Test

334 Euro Screws are Included with the 320 Zero
Other screws are In-Progress, Please call the check availability.

  • 335 Euro Screws, Cutoff to 5/16" Thread Length
  • 336 Combination Screws, 1-1/2" Thread Length
  • 238 Combination Screws, 9/16" Thread Length
  • 238 Machine Thread, 10 -24, 9/16" Thread Length

More Information is Available Under "Video/Downloads"

Quick Introduction Animation:

Shop Demonstration Videos:

Product Specifications:

320 Zero, Specs, 1-28-19 (pdf)
